NMQB24-MFT | Belimo | Damper Actuator

  • SKU: NMQB24-MFT

Regular price
$769.00
Sale price
$322.98
Unit price
per

Availability:

Estimated delivery in 4-7 business days


NMQB24-MFT Damper Actuator, multifunctional control 24V non-spring return



For proportional modulation of dampers in HVAC systems. Actuator sizing should be done in accordance with the damper manufacturer’s specifications.

The actuator is mounted directly to a damper shaft up to 1.05” in diameter by means of its universal clamp, 1/2” self centered default. A crank arm and several mounting brackets are available for applications where the actuator cannot be direct coupled to the damper shaft.

The default parameters for 2 to 10 VDC applications of the …MFT actuator are assigned during manufacturing. If necessary, custom versions of the actuators can be ordered. The parameters can be changed by two means: pre-set and custom configurations from Belimo or on-site configurations using the Belimo PC-Tool software (version 3.3 or later).



Download the Data Sheet

Download the Installation Guide




Request a Quote
