LF24-SR US | Belimo | Damper Actuator

  • SKU: LF24-SR US

Regular price
$681.00
Sale price
$374.55
Unit price
per

Availability:

Estimated delivery in 4-7 business days


LF24-SR US Damper Actuator, proportional, 24V, spring return (fail-safe)



For fail-safe, modulating control of dampers in HVAC systems. Actuator sizing should be done in accordance with the damper manufacturer’s specifications. The actuator is mounted directly to a damper shaft from 3/8” up to 1/2” in diameter by means of its universal clamp, 1/2” shaft centered at delivery. For shafts up to 3/4” use K6-1 accessory. A crank arm and several mounting brackets are available for applications where the actuator cannot be direct coupled to the damper shaft. The actuator operates in response to a 2 to 10 VDC, or with the addition of a 500? resistor, a 4 to 20 mA control input from an electronic controller or positioner. A 2 to 10 VDC feedback signal is provided for position indication.



Download the Data Sheet

Download the Installation Guide




Request a Quote
