LF24-S US | Belimo | Damper Actuator
- SKU: LF24-S US
LF24-S US Damper Actuator, On/Off, 24V, spring return (fail-safe), built-in auxiliary switch
For On/Off, fail-safe control of dampers in HVAC systems. Actuator sizing should be done in accordance with the damper manufacturer’s specifications. Control is On/Off from an auxiliary contact or a manual switch. The actuator is mounted directly to a damper shaft from 3/8” up to 1/2” in diameter by means of its universal clamp, 1/2” shaft centered at delivery. For shafts up to 3/4” use K6-1 accessory. A crank arm and several mounting brackets are available for applications where the actuator cannot be direct coupled to the damper shaft.
Download the Data Sheet
Download the Installation Guide
