LF24-3 US | Belimo | Damper Actuator
- SKU: LF24-3 US
Estimated delivery in 4-7 business days
LF24-3 US Damper Actuator, On/Off, floating point, 24V, spring return (fail-safe)
For modulation or On/Off, fail-safe control of dampers in HVAC systems. Actuator sizing should be done in accordance with the damper manufacturer’s specifications. The actuator is mounted directly to a damper shaft from 3/8” up to 1/2” in diameter by means of its universal clamp, 1/2” shaft centered at delivery. For shafts up to 3/4” use K6-1 accessory. A crank arm and several mounting brackets are available for applications where the actuator cannot be direct coupled to the damper shaft. Control is floating point from a triac or relay, or On/Off from an auxiliary contact from a fan motor contactor, controller or manual switch.
Download the Data Sheet
Download the Installation Guide
