AMCX24-MFT | Belimo | Damper Actuator

  • SKU: AMCX24-MFT

Regular price
$886.00
Sale price
$487.30
Unit price
per

Availability:

Estimated delivery in 4-7 business days


Configurable, Damper Actuator, 180 in-lbs [20 Nm], Non fail-safe, AC/DC 24 V, DC 2...10 V



For proportional modulation of dampers in HVAC systems. Actuator sizing should be done in accordance with the damper manufacturer’s specifications. The actuator is mounted directly to a damper shaft up to 1.05” in diameter by means of its universal clamp. A crank arm and several mounting brackets are available for applications where the actuator cannot be direct coupled to the damper shaft. The default parameters for 2 to 10 VDC applications of the …MFT actuator are assigned during manufacturing. If necessary, custom versions of the actuators can be ordered. The parameters can be changed by two means: pre-set and custom configurations from Belimo or on-site configurations using the Belimo PC-Tool software.
